Additional Parts |
|
GEP-CLIP-XM03 |
|
Electrical Specifications for Speaker Section
|
|
Item |
Value |
Conditions |
|
1-1 Speaker Dimensions |
Φ44.6 x 8.3mm |
|
1-2 Impedance |
8Ω ± 15% |
|
|
1-3 Rated Input Power |
2.0W |
|
|
1-4 Max. Input Power |
3.0W |
|
|
1-5 output S.P.L. |
86dB ± 3dB |
0.5M average 1000, 1200, 1500, 2000HZ |
|
1-6 Frequency Response |
300HZ ~ 18KHZ |
Average SPL-10dB |
|
1-7 Distortion |
5% Max |
1.0KHz/ 1.0W |
|
Electrical Specifications for Microphone Section
|
|
Item |
Value |
|
2-1 Type and Dimension |
Condenser Type, Dimension = Φ6.0 x 5.0mm |
|
2-2 Output Impedance |
2.2KΩ ± 10% |
|
2-3 Sensitivity |
-40dB ± 3dB |
|
2-4 Frequency Range |
50Hz~20KHz |
|
2-5 Directivity |
Omni-directional |
|
2-6 Operation Voltage |
Standard Voltage 3V Max. Operation Voltage 10V |
|
2-7 S/N Ratio |
More Than 58dB |
|
