Additional Parts |
|
A1311-0001-1 (Clip) |
|
Electrical Specifications for Speaker Section
|
|
Item |
Value |
Conditions |
|
1-1 Speaker Dimensions |
Φ36 x 5.0mm |
|
1-2 Impedance |
8Ω ± 15% |
At 1.2KHZ, 1.0 Vrms |
|
1-3 Rated Input Power |
1.0W |
|
|
1-4 Max. Input Power |
1.5W |
|
|
1-5 output S.P.L. |
89dB ± 3dB |
0.5M average 1000, 1200, 1500, 2000HZ |
|
1-6 Frequency Response |
380HZ ~ 5.6KHZ |
Average SPL-10dB |
|
1-7 Distortion |
<5% Max |
1.0KHz/ 2.83 Vrms |
|
Electrical Specifications for Microphone Section
|
|
Item |
Value |
|
2-1 Type and Dimension |
Condenser Type, Dimension = Φ6.0 x 3.6mm |
|
2-2 Output Impedance |
2.2KΩ ± 10% |
|
2-3 Sensitivity |
-44dB ± 2dB |
|
2-4 Frequency Range |
50Hz~20KHz |
|
2-5 Directivity |
Omni-directional |
|
2-6 Operation Voltage |
Standard Voltage 2.5V
Max. Operation Voltage 10V |
|
2-7 S/N Ratio |
Typical 60dB |
|
