Additional Parts |
GEP-CLIP-M01
GEP-CLIP-PT |
|
Electrical Specifications for Speaker Section
|
|
Item |
Value |
Conditions |
|
1-1 Speaker Dimensions |
Φ36 x 5.2mm |
|
1-2 Impedance |
8Ω ± 15% / 16Ω ± 15% |
1.2KHz/ 1.0V |
|
1-3 Rated Input Power |
1.0W |
|
|
1-4 Max. Input Power |
1.5W |
|
|
1-5 Sensitivity |
89 ± 3dB/ 104dB ± 3dB |
|
|
1-6 Frequency Response |
380HZ ~ 5.6KHZ |
Average SPL-10dB |
|
1-7 Distortion |
5% Max |
1.0KHz/2.83W |
|
Electrical Specifications for Microphone Section
|
|
Item |
Value |
|
2-1 Type and Dimension |
Condenser Type, Dimension = Φ6.0 x 5.0mm |
|
2-2 Output Impedance |
2.2KΩ ± 10% |
|
2-3 Sensitivity |
-44dB ± 3dB |
|
2-4 Frequency Range |
50Hz ~ 20KHz |
|
2-5 Directivity |
Omni-directional |
|
2-6 Operation Voltage |
Standard Voltage 3V Max. Operation Voltage 10V |
|
2-7 S/N Ratio |
More Than 58dB |
|
